Description MR289625 HRK6723 Brake Shoe Set SET Rear Axle
Diameter : 228 mm
Width : 30 mm
| Model | Engine | Chassis | Type | CYL | year | ||
|---|---|---|---|---|---|---|---|
| CHANGFENG LIEBAO CS7 Closed Off-Road Vehicle | 5/09 - 2/12 | ||||||
| CHANGFENG LIEBAO Closed Off-Road Vehicle | 9/04 - / | ||||||
| MITSUBISHI (BJC) OUTLANDER (GU_W) | 1/04 - 3/06 | ||||||
| MITSUBISHI GRANDIS (NA_W) | 4/04 - 2/11 | ||||||
| MITSUBISHI OUTLANDER I (CU_W) | 5/03 - 0/06 | ||||||
| MITSUBISHI PAJERO PININ (H6_W, H7_W) | 0/00 - 6/07 | ||||||
| MITSUBISHI SPACE RUNNER (N50) | 8/99 - 8/02 | ||||||
| MITSUBISHI SPACE WAGON (N3_W, N4_W) | 0/92 - 0/98 | ||||||
| MITSUBISHI SPACE WAGON (N9_W, N8_W) | 0/98 - 2/04 | ||||||
Application
MITSUBISHI AIRTREK CU4W 2400 01' 6-
MITSUBISHI AIRTREK CU2W 2000 2WD 01' 6-
MITSUBISHI LANCER CS2A 1500 4WD 03' 2-
MITSUBISHI MIRAGE DINGO CQ2A 1500 4WD 01' 2-02' 8
MITSUBISHI LANCER CARGO CS2V 1500 03' 1-
MITSUBISHI LANCER CEDIA / WAGON CS5W 1800 4WD 00' 11-03' 1
MITSUBISHI PAJERO io H66W 1800 3 4WD 98' 6-00' 6
MITSUBISHI PAJERO io H76W 1800 5 4WD 98' 6-
MITSUBISHI PAJERO io H71W 1800 5 99' 8-00' 6
MITSUBISHI PAJERO io H72W 2000 5 00' 5-
MITSUBISHI PAJERO io H62W 2000 3 00' 5-
MITSUBISHI PAJERO io H77W 2000 5 4WD 00' 5-
MITSUBISHI PAJERO io H61W 1800 3 99' 8-00' 6
MITSUBISHI PAJERO io H67W 2000 3 4WD 00' 5-
MITSUBISHI PAJERO MINI H53A 660 2WD 98' 9-
MITSUBISHI PAJERO MINI H58A 660 4WD 98' 9-
MITSUBISHI CHARIOT GRANDIS N94W 2400 00' 7-03' 4
MITSUBISHI CHARIOT GRANDIS N84W 2400 97' 10-00' 6
MITSUBISHI CHARIOT GRANDIS N84W 2400 00' 7-03' 4
MITSUBISHI CHARIOT GRANDIS N94W 2400 97' 10-00' 6
MITSUBISHI TOWN BOX WIDE U65W 1100 2WD 99' 3-01' 5
MITSUBISHI TOWN BOX WIDE U66W 1100 4WD 99' 3-01' 5
MITSUBISHI DION CR6W 2000 02' 6-
MITSUBISHI DION CR9W 2000 00' 1-02' 6
MITSUBISHI DION CR5W 1800 02' 6-
MITSUBISHI AIRTREK CU2W 2000 2WD 01' 6-
MITSUBISHI LANCER CS2A 1500 4WD 03' 2-
MITSUBISHI MIRAGE DINGO CQ2A 1500 4WD 01' 2-02' 8
MITSUBISHI LANCER CARGO CS2V 1500 03' 1-
MITSUBISHI LANCER CEDIA / WAGON CS5W 1800 4WD 00' 11-03' 1
MITSUBISHI PAJERO io H66W 1800 3 4WD 98' 6-00' 6
MITSUBISHI PAJERO io H76W 1800 5 4WD 98' 6-
MITSUBISHI PAJERO io H71W 1800 5 99' 8-00' 6
MITSUBISHI PAJERO io H72W 2000 5 00' 5-
MITSUBISHI PAJERO io H62W 2000 3 00' 5-
MITSUBISHI PAJERO io H77W 2000 5 4WD 00' 5-
MITSUBISHI PAJERO io H61W 1800 3 99' 8-00' 6
MITSUBISHI PAJERO io H67W 2000 3 4WD 00' 5-
MITSUBISHI PAJERO MINI H53A 660 2WD 98' 9-
MITSUBISHI PAJERO MINI H58A 660 4WD 98' 9-
MITSUBISHI CHARIOT GRANDIS N94W 2400 00' 7-03' 4
MITSUBISHI CHARIOT GRANDIS N84W 2400 97' 10-00' 6
MITSUBISHI CHARIOT GRANDIS N84W 2400 00' 7-03' 4
MITSUBISHI CHARIOT GRANDIS N94W 2400 97' 10-00' 6
MITSUBISHI TOWN BOX WIDE U65W 1100 2WD 99' 3-01' 5
MITSUBISHI TOWN BOX WIDE U66W 1100 4WD 99' 3-01' 5
MITSUBISHI DION CR6W 2000 02' 6-
MITSUBISHI DION CR9W 2000 00' 1-02' 6
MITSUBISHI DION CR5W 1800 02' 6-
- Recommends every 5,000 km check Brake System
ensure the normal operation of the braking system - Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
- Rear brakes is recommended to replace within 5-7 km
- Replace the Disc brake when follow situation happen:
- 1.Sensor alarm;
- 2.Friction materials thickness less than 3mm;
- 3.Friction materials becomes contaminated with brake fluid;
- 4.Uneven wear within a set;
- Replace the brake rote when follow situation happen:
- 1.Vibrate when braking;
- 2.Car vehicle performance more than 60000Km and braking unstable;
- 3.Disc brake thickness wear more than 2mm;
